The relevant knowledge of curtain wall drawings is to understand, so as to be more convenient to design in the later period, avoid the deposits of some details, and ensure normal construction. So what are the entry knowledge of curtain wall drawings?

First, what are the entry knowledge of curtain wall drawings.

1. Hurry parts: Some construction projects do not design embedded parts, so they need to be remedied with expansion bolts and chemical bolts during construction, while some have embedded parts. It is difficult to meet the requirements of construction specifications.

2. Pillar beam part: The mechanical computing model of the pillar is difficult to meet the needs of the actual project. In addition, the characteristics of the characteristic parameters of the column beam section are inaccurate or there are errors, and even the shape of some sections cannot meet the strength requirements. In order to be compressed, although the strength of the component of the component is not checked, some of the components are not checked, and some have not been checked according to the poor grid and large span.

3. At the connection between the curtain wall and the main body: the intensity of the welding of the bracket and the plate does not meet the requirements of the construction specifications. Only one bolt is installed at the connection at the connection, resulting in the bending corner code torque is too large and it is difficult to reinforce.

4. The fixed position of the board: There is no support pole under the hidden frame wall board, the gap between the pressure plate is too large, and the pressure on the board itself does not meet the construction specification requirements.

5. Fire prevention and lightning protection parts: The thickness of the waterproof cotton use is difficult to meet the requirements of construction specifications, the waterproof partition is thin, the waterproof seam is not tight enough, and the posture of the column is improperly treated.

6. The structure of the curtain wall: The curtain wall is a replaceable structure. The structure of the structure is not less than 25 years. The integrated parts are not easy to replace. It should be considered 50 years. Consider.

Glass curtain wall, metal board curtain wall, stone board curtain wall, color concrete hanging board curtain wall, unit combination curtain wall.

1. Metal board curtain wall: similar to the glass curtain wall, which is customized by the factory customized metal plate as the peripheral wall surface, combined with the window to form a curtain wall, forming a glittering metal wall, has its unique modern artistic sense. It It has the advantages of elegant and solemn, rich texture and solid, durable, easy to disassemble.

2. Silent curtain wall: From the characteristics of the exterior wall of the building, the stone board curtain wall is a complete, independent encirclement structure system. As a framework structure, the specially designed independent metal skeleton system should be hung on the main structure, and then the stone decorative panel is hung on the metal skeleton via metal pendant. The role of the main structure can be adapted to the impact of the structure displacement of the main body.

3. Glass curtain wall: It is mainly used for the material of glass, covering the surface of the building, and it looks like a layer of laminar covered on the appearance of the building, especially the use of hot reflected glass (mirror glass) to use it. Natural phenomena such as blue sky, Baiyun, etc., to varying degrees, the surface of the building is reflected, so that the appearance of the building is intertwined, there is a sense of unpredictable feeling, and the building curtain wall.
