1. The advantages of broken bridge aluminum

(1) Reduce thermal conductivity: Use thermal insulation bridge aluminum alloy profile, with a heat conduction coefficient of 1.8 3.5W / · k, far lower than ordinary aluminum alloy profiles 140 170W / · k; It is 2.0 3.59W / m · k, which is far lower than the general aluminum alloy profile 6.69 6.84W / · k, which effectively reduces the thermal conductivity of the doors and windows.

(2) Prevent condensation: The temperature in the inner surface of the profile with insulation strip is close to the indoor temperature, reducing the possibility of indoor humidity on the surface of the profile due to excessive saturation.

(3) Energy -saving: In winter, the window frame with insulation strip can reduce 1/3 of the calories emitted by the window frame; in summer, if there is an air conditioner, the window frame with insulation strip can further reduce energy loss.

(4) Protection of the environment: By adopting the insulation system, it can reduce energy consumption and reduce environmental radiation caused by air conditioning and heating. It is beneficial to health: The heat exchange between the human body and the environment depends on the temperature of indoor air, air flow rate and outdoor air temperature.

By adjusting the indoor temperature of the doors and windows, it can achieve the most comfortable environment.

(5) Reduce noise: The use of a hollow glass structure of different thickness and the air cavity structure of the thermal insulation aluminum bridge can effectively reduce the resonance effect of sound waves, prevent sound transmission, and reduce the noise by more than 30DB.

(6) Bright colors: After the anode oxidation, powder spraying and carbon fluoride spraying surface treatment, aluminum profiles of different colors can be produced. After rolling and combination of thermal aluminum alloy doors and windows, two different colors of different colors of indoor and outdoor can be produced.

2. Broken bridge aluminum performance

(1) Broken bridge aluminum doors and windows have good thermal insulation. The internal framework and outer frame of thermal insulation profile combine softness. The framework adopts a three -seal form, a rubber strip and a double top, with a close seal, excellent gas and water density, and excellent thermal insulation performance. , Insulation, excellent functions, a large amount of heating and cooling costs. The testing coefficient K value is tested below 2.23-2.94W / 2K. The energy -saving effect is significant. The energy -saving cost of several years is enough to make up for the initial investment.

(2) Waterproofing function of baying doors and windows. The structural drainage system is designed with the principle of pressure balance. The slope is designed to slide up and fall, the drainage port, smooth drainage, and good water density.

(3) Anti -condensation and anti -frost on the aluminum doors and windows of the broken bridge. Broken bridge aluminum profiles can realize the three -way sealing structure of the doors and windows, reasonably separate the water vapor cavity, and successfully achieve the average pressure balance of water and water, which greatly improves the water density and gas density windows of the doors and windows, and achieved clear and bright window effects.

(4) Design of anti -mosquito nets for broken bridges and windows and windows. The invisible screen window can be installed and used inside and outside. It has the effect of anti -mosquito and flies, especially suitable for northern mosquito regions.

(5) Anti -theft and anti -pine device for broken aluminum doors and windows. Equipped with standard hardware locks to ensure the stability and safety of the windows in use.

(6) Broken bridge aluminum doors and windows will prevent noise and sound insulation. The structure is carefully designed and the joints are close. After testing, the air sound insulation capacity reaches 30--40DB, which can ensure that residents on the two sides of the highway will not be disturbed by noise, and the neighboring urban areas can also ensure that the internal is quiet and warm. (7) Fire function of broken bridge aluminum doors and windows. Aluminum alloy is made of metal, and the insulation belt is made of PA66 GF25 (usually called nylon insulation belt). (8) Broken bridge aluminum doors and windows, sand preventing sand and windproof pressure. The straight material of the inner frame adopts hollow design, wind resistance, strong resistance to deformation, and good anti -vibration effect. It can be used for high -rise buildings and civilian houses. Large -scale windows can be designed to have a large lighting area; this window has good gas tightness and can ensure that the indoor windowsill and floor of the sandstorm are not dusty. (9) The aluminum doors and windows of the broken bridge are high, intangible and exempt maintenance. The aluminum windows of the broken bridge have high tensile stretching and shear strength and high heat resistance deformation. The aluminum material of the broken bridge is not easy to be corroded by acid and alkali, it is not easy to turn yellow and fade, and there is almost no need to maintain. (10) Broken bridge aluminum doors and windows have a variety of colors and very decorative. It can realize the different colors of the interior and outside surfaces of the doors and windows, meet customers' preferences for color effects, the beauty of color gamut space, and meet the requirements of the architect's personalized design requirements.

The aluminum profile adopts a streamlined design with luxurious style. (11) Broken bridge aluminum doors and windows green building materials, circular economy. Broken bridge aluminum doors and windows not only do not produce harmful materials during the production process, but all materials can be recovered and reused. They are green building materials and environmental protection products, which are in line with the sustainable development of human beings. (12) There are many opening forms of the broken bridge aluminum doors and windows, which are comfortable and durable. There are flat -opening, tilted inward, top suspension, push -pulling, flat opening, and inclined inward combination.

3. The application scope of the broken bridge aluminum doors and windows

(1) Suitable for public buildings, residential areas and municipal engineering; high -quality hardware accessories are durable, operating the humanized design of the handle, beautiful and comfortable, easy to open and flexible. Second, it is easy to slide and silent. Mature and complete doors and windows processing technology, high -precision program -controlled processing centers are produced, and quality is guaranteed.

(2) The prominent advantages of the insulation and broken bridge aluminum alloy doors and windows are: high strength, good thermal insulation, good rigidity, good fire prevention, large lighting area, good atmospheric corrosion resistance, high comprehensive performance, long service life and decorative effects effect good. High -end aluminum alloy doors and windows are the first choice for high -end building windows.

4. Classification of Broken Bridge Aluminum Doors and Windows

(1) The hanging window on the top suspension is only aluminum alloy and plastic steel windows that appear in the future. It is a new form developed on the basis of open windows. It has two ways to open it, which can be opened horizontally or pushed away from the top. When the window is turned off, the upper part of the window is pulled inward to open a gap of about ten centimeters. In other words, the windows can be opened slightly from the top, and the open part is hung in the air and is fixed with the window frame through the hinge. Called a suspension. Its advantages are: it can ventilate, but also ensure safety.

Because there are hinges, the windows can only be opened with a seam of ten centimeters, and it cannot be reached from the outside. It is especially suitable for no one at home.

This function is not limited to the flat window, but also can open the sliding window.

(2) There is a single opening and double -opening door open door when opening the door: only one door panel, while the double door has two door panels. The flat door is divided into one -way and two -way opening. One -way opening means that it can only be opened in one direction (can only push inward or outward). Two -way opening means that the door fan can be opened in two directions (such as spring doors). The difference between the side door and other opening methods is that the door also has the characteristics of mobile type opening, upward, rolling curtains, rolling rosses, rotation and other characteristics.

(3) Sliding doors and moving doors originated in China and spread to South Korea and Japan through Chinese culture. Literally: sliding doors; from the perspective of materials: there are wood, metal, organic and inorganic materials. From the perspective of use: for bookcases, wall cabinets, bedrooms, living rooms and exhibition halls. Moving the door originated in China and spread to South Korea and Japan through Chinese culture. The exact time is unclear, but you can see the scattered sliding doors in some ancient Chinese paintings, such as the sliding door in the Song Dynasty landscape paintings. The first door movement was only used for the migration door of the bedroom or locker room wardrobe, but with the development of technology and the diversification of decorative methods, traditional from the surface of the wooden board to the glass, fabric, rattan, aluminum alloy profile, sliding door, folding, folding The function and use range of sliding doors are continuously expanding. In this case, the use of sliding doors becomes diverse and enriched.

In addition to the most common partition door, the sliding door is also widely used in bookcases, wall cabinets, living rooms, exhibition halls, and sliding doors.

5. How do consumers buy broken bridge and aluminum doors and windows?

(1) The thickness of the aluminum profiles used in the material of the material of the material, and the intensity and oxide film should meet the relevant national standards. The wall thickness of the non -elastic assembly structure of the window is greater than 1.4mm, and the wall thickness of the non -elastic assembly structure of the door is greater than 2.0mm. The stretching strength should reach 157 Newton per square millimeter, the yield strength should reach 108 Newton per square millimeter, and the thickness of the oxide film should reach 10 microns.

If the above standards are not met, the doors and windows of inferior aluminum alloy cannot be used.

(2) Machining high -quality aluminum alloy doors and windows, fine processing, careful installation, good sealing performance, convenient opening and closing, inferior aluminum alloy doors and windows and blind selection of aluminum profile series and specifications, processing with subsequent products, cutting instead of milling, installation is not as required as required , Poor sealing performance, uncomfortable opening and closing, not only leakage, glass explosion, but also strongly scratching or tapping sliding parts or glass under the action of wind and external force, causing property loss and personnel damage.

(3) Under normal circumstances, due to the high production cost, high -quality aluminum alloy doors and windows are about 30 % more expensive than inferior aluminum alloy doors.

The wall thickness of some aluminum doors and windows made of aluminum profiles is only 0.6-0.8 mm. Its tensile strength and yield strength are much lower than related national standards, and it is very unsafe.
