Stone curtain wall sales structure: This structure belongs to the first generation of stone dry hanging technology. It is drilling on the upper and lower end surface of the slate.

This structure is simple, but the surface of the board is local force, which is prone to squeezing stress. The plate has a poor resistance to deformation, and it should not be replaced after the plate is damaged. It is suitable for low -rise buildings. Structure of stone curtain wall semi -round grooves: This structure belongs to the second -generation product of stone dry hanging technology, refers to the upper and lower ends of the slate to milling into a semi -circular groove. Absorbing deformation, considering the strength problem, generally use stainless steel hook boards, but it is not advisable to replace after the plate is damaged. It is suitable for low -rise buildings. The fixing method of long slot fixing of the stone curtain wall: This structure is opened on the upper and lower ends of the slate, and the aluminum alloy long hook board is fixed. It is characterized by reasonable force, high reliability, strong anti -deformation capacity, and the sector is damaged After that, the replacement requirements can be implemented, suitable for high -rise buildings. Stone curtain wall back embolism structure: This structure belongs to the third -generation product of stone dry hanging technology. It is currently more advanced technology in the world. In China, only our company has this technology, processing and construction technology and import special processing equipment. The direction of the development of the curtain wall technology is characterized by the non -stress processing of the stone. The back of the stone is connected with stainless steel bloating. The connection intensity is high, saving about 30%of the intensity value, the plate has strong resistance to deformation, and the replacement requirements can be achieved after the sector is damaged. It is suitable for high -rise buildings. Comparison of stone dry hanging process 1. Node structure S and characteristic plates on the side of the characteristic board are opened short slots, T -films are fixed, and pendant plates are contacting the side of the surface of the plate to contact the side of the plate, the hook pendant is fixed, the pendant and the board contact are contact with the back of the plate to contact the back of the plate. Drilling, Germany's wisdom fish rear anchor embolism is fixed, anchor bolt and plates are three -dimensional embedded fixation 2. Disposable method T -board is cut, stone is partially cut, large surface is bent, and the edge of the plate is cut. Partially cut, bending large surface, fixed anchor embolism at the edge of the plate, partially cutting pressure on the stone, bending on the large surface, fixed in the middle of the plate 3. The long -round hole adjustment on the installation and pendies of the plate is opened. The installation is simple to install. The pendant is not adjusted before and after, the precision requirements for the installation of keel and attachment are high, and the installation is difficult before and after in the installation. The precision requirements for the installation of keel and attachment are high. There is a certain difficulty in installation. The system of aluminum alloy keel system or aluminum alloy keel system or aluminum alloy and steel shared system of aluminum alloy and steel. A hanging point yuan, but the number of pendants is doubled than the T pendant, which requires special equipment due to drilling pores, and must purchase supporting equipment and anchor bolts. The quantity increases by about double than the T pendant 6. The construction period of the construction period is good, the construction is simple, the construction period is high, the construction period is high, the construction period is difficult, the long -term pendant adjustment requirements are high, the construction is difficult, the construction period is longer, the construction period is longer 7. The appearance effect is highly adjusted, which is easy to ensure the flatness of the facade. The decorative effect is reasonable to adjust the structure design. The flatness and decorative effect of the decorative effect can be used to highlight the texture and three -dimensional sense of the stone curtain wall through the gel sewing 8. The processing board of the board and pendant location is processed on -site. Adjust the board drilling factory processing, the on -site size is not easy to adjust 9. The maintenance and replacement and replacement of the board can be replaced. The corrosive material is stainless steel, the well -antifrocrosted performance is aluminum alloy, the preserved corrosion performance is stainless steel, and the corrosion performance is good 11. Other stone curtain wall systems suitable for dense seals, but can be used to ensure stone materials by retreating gels to ensure stone materials The three -dimensional sense, the stone curtain wall system that can be used for the seaming system and the glue -to -glue, is suitable for the open sewing stone curtain wall system that does not glue
